- Light Source:LED
- Item Type:Explosion-proof Lights
- Place of Origin:CN
- IP Rating:IP68
- Working Temperature(℃):-40 - 50
- Working Lifetime(Hour):100000
- Input Voltage(V):100-277V
- LED Light Source:USA Cree,USA Bridgelux
- Color Temperature(CCT):Cool white ,warm white
Anti-explosion gas station led light with IP68 Bridgelux,cree leds
Total Power Consume | 120w |
Whole Fixture Lumen | ≥9,840 lm |
LEDChip/Brand | 96xUSABridgelux,700ma chip |
LED Efficacy | 120lm – 130 lm @ 350Ma (350Ma ≡1w) |
Illuminant | equal to HPS 400 ~ 500w* |
Input | 100-277V |
Hz | 50/60 Hz |
Power Factor | ≈ 0.98 |
Driver Efficiency | ≈ 90% |
CRI |
≥ 70% |
Colour Temperature | Warm White:2700 - 4000k Cool White:5500 - 6500k |
Driver | Meanwell HLG Series |
Ingress Protection | IP68 |
Body Material | Die Cast Aluminum |
Dimension | 400 x 400 x 185 mm |
Packing Size | 480 x 480 x 260 mm |
Feature | Anti Explosive : Class “E” - Gas filled environment |
Operating Temperature | -40C - 50C |
Net Weight | 12.5KG |
LEDLife Span | 50,000 – 100,000Hours |
Height (M) | Central Lux(lx) | Area Cover (M) |
2.5 | 1209.5 | 1.3m x 2.8m |
5 | 302.4 | 2.6m x 5.6m |
7.5 | 134.4 | 3.9m x 8.4m |
10 | 75.6 | 5.3m x 11.1m |
12.5 | 48.4 | 6.5m x 13.9m |
15 | 33.6 | 7.9m x 16.7m |
